HIK Micro Habrok Pro 4K 35mm Multi-Spectrum Thermal / Digital Binoculars - HQ35L4K

PLEASE NOTE: DUE TO INTERNATIONAL SHIPPING RESTRICTIONS WE ARE ONLY ABLE TO DISPATCH THERMAL/NIGHT VISION OPTICS TO ADDRESSES IN THE UNITED KINGDOM.

HikMicro Habrok Pro 4K 35mm Thermal (640x512) Binoculars with LRF. HIKMICRO have upped the ante again, by taking the proven Habrok 4K chassis and putting it on steroids by upgrading to a 640x512 sub 20mK NETD Thermal Detector coupled to a 35mm F1.0 lens, added EIS Image Stabilisation. Topped off by supplying additional wavelength IR illuminator and a bino harness to the package.

Features
4K UHD 3840x2160px CMOS detector for incredible detail and 400m night detection range.
60mm F2.2 digital lens with 5.5-22.0x magnification. 12.6m FOV at 100m
EIS Electronic Image Stabilisation
Integrated 940nm IR Illuminator, with additional swappable 850nm unit
640x512px sub 20mK NETD Thermal Detector with 1800m detection range
35mm F1.0 thermal lens with 3.0-22.0x magnification. 22.0m FOV at 100m
1920x1080px 0.49” OLED sub-round display
Integrated Laser Range Finder with 10-1000m range
8h+ run time 18650 battery system
Black Hot, White Hot, Red Hot & Fusion Thermal Palettes
Day, Night & Auto Optical modes
60-74mm adjustable interpupillary distance and foldable eyepieces
Rugged and compact magnesium construction. Less than 800g weight
Specifications

Thermal Module
Sensor Type: VOx Uncooled Focal Plane Array
Resolution: 640 × 512
Frame Rate: 50 Hz
Pixel Pitch: 12 μm
Spectral Range: 8 μm – 14 μm
Thermal Sensitivity (NETD): < 20 mK (@25°C, F#=1.0)
Lens: 35 mm, F1.0
Focus Mode: Manual (Focus Ring)
Detection Range: 1800 m
Minimum Focusing Distance: 3.5 m
Magnification: 3.0× to 22.0× (7.3× base)
Field of View (H × V):
12.5° × 10.1°
22.0 m × 17.6 m @ 100 m

Optical Module
Sensor Type: 1/1.8" Progressive Scan CMOS
Resolution: 3840 × 2160
Lens: 60 mm, F2.2
Minimum Working Distance: 3 m
Focus Mode: Manual (Focus Ring)
Magnification: 5.5× to 22.0× (4× base)
Field of View (H × V):
7.3° × 4.1°
12.6 m × 7.2 m @ 100 m

Infrared Illumination
Smart IR: Yes
IR Illuminator: Replaceable
Default: 940 nm
Optional: 850 nm
Night Viewing Range: 400 m

Image Display
Display: 0.49 inch OLED, 1920 × 1080
Thermal Palettes: Black Hot, White Hot, Red Hot, Fusion
Optical Modes: Day, Night, Auto
Flat Field Correction (FFC): Auto / Manual / External
Exit Pupil: 8 mm
Eye Relief: 15 mm
Diopter Adjustment: -5 D to +3 D
Adjustments:
Brightness: Yes
Contrast: Yes
Tone: Cold / Warm
Zoom Pro: Yes

System Features
Video Recording: Yes
Snapshot Capture: Yes
Audio Recording: Yes
Standby Mode: Yes
Onboard Storage: 64 GB Built-in EMMC
Picture-in-Picture (PIP): Yes
Wi-Fi Hotspot: Yes
Hot Track: Yes
Digital Magnetic Compass: Yes
GPS Module: Yes
Local Album Access: Yes

Power Supply
Battery Type: Replaceable & Rechargeable 18650 Li-ion
Operating Time: ≥8 hours (@25°C, Hotspot off)
Charging & Power:
USB Type-C: 5 V DC, 2 A
Supports external power and direct charging

General
Protection Level: IP67
Dimensions: 138.1 mm × 68.5 mm × 222.4 mm (5.44" × 2.7" × 8.75")
Weight: 798 g (without battery)
Interpupillary Adjustment Range: 60 mm – 74 mm
Mounting: 1/4"-20 UNC Adapter
Operating Temperature: -30°C to +55°C

Laser Rangefinder
Laser Class: Class 1
Wavelength: 905 nm
Measuring Range:
Minimum: 10 m
Maximum: 1000 m
Accuracy: ±1 m
